Machine Bolt - Hex Head - Hot Dip Galvanized Steel - 1/2"-13 Thread - 12" Long
Kanebridge
Item #
AM5686
Mfr. Model #
50192BMG
Machine bolts are used with hex nuts or with a tapped hole. The hex head has an external hex head that protrudes above the surface. The external hex drive is designed to be used with a ratchet. Hot dip galvanized steel offers good corrosion resistance.
Specifications
| Body Width | 0.499" |
|---|---|
| Body Width Tolerance | (-0.017" to +0.017") |
| Bolt Subtype | Standard |
| Bolt Type | Machine |
| Brand Name | Kanebridge |
| Brand Part Number | 50192BMG |
| Drive Style | External Hex |
| Finish | Hot Dip Galvanized |
| Head Height | 11/32" |
| Head Subtype | Standard |
| Head Type | Hex |
| Head Width | 3/4" |
| Length | 12" |
| Material | Steel |
| Min Thread Length | 1-1/2" |
| Pack Quantity | 1 |
| Specifications Met | ASME B18.2.1 |
| System of Measurement | Inch |
| Tensile Strength | 60,000 psi |
| Thread Direction | Right |
| Thread Size | 1/2"-13 |
| Thread Spacing | Coarse |
| Thread Type | UNC |
| Threading | Partially Threaded |
$4.24
/
each
Expected to ship Mon. Dec 11
